Name: Portable Mini Muffle Furnace for STM-3-12 Laboratories
Brand: Portable Mini Muffle Furnace for STM-3-12 Laboratories
SKU: STM-3-12
Rating: 4.6 (111 reviews)

traits Galerie Description de produit Demandez une citation

traits

Caractéristiques

Warranty: 1 years, 1 Year

Classification: Laboratory Heating Equipments

Customized support: OEM, ODM

Model Number: STM-3-12

Product name: Portable Mini Muffle Furnace for Labs

Type: Benchtop

Max temperature: 1000â„ƒ

Continuous temperature: 900â„ƒ

Power supply: AC:220V 50Hz 2.5KW

Heating element: Electric Resistance Wire

Temperature accuracy: Â±1â„ƒ

Thermocouple: N type

Certification: ISO9001; CE

Informations de base

Certification: ISO9001; CE

Model Number: STM-3-12

Conditions de paiement et expédition

Packaging Details: 1.Plastic stretch-wrap 2.Polyfoam filled 3.Plywood carton

Supply Ability: 1000 Set/Sets per Year

Description de produit

Portable Mini Muffle Furnace for Labs

The 1000°C muffle furnace (box type resistance furnace) mainly provides high temperature heat treatment environment for industrial colleges, research institutes, factories and other industrial laboratories, and is applied to new materials such as metal materials, ceramic materials, nano materials, and semiconductor materials.

when the proximity Switch detects the door opens, Drop-down Door serves as a convenient shelf for the power will be cut off automatically.When the door laoding and unloading samples. closed, the furnace will be continuously heated.

Highe-precision Digital microprocessor controller High quality alloy resistance wire(HRE)

fitted with self -tuning and manual PID settings

makes temperature and other parameters esay to control

Product Description

Portable Mini Muffle Furnace for Labs

Model	STM-3-12	STM-6-12	STM-8-12	STM-12-12	STM-18-12	STM-30-12	Customized
Chamber size(WxLxH)mm	150x150x150	180x230x150	200x300x120	200x300x200	250x300x250	300x500x200	Any size
Type	Benchtop
Furnace structure	Chamber material, temperature controller system, heating element, furnace shell and other assistant parts
Max temperature	1200℃
Continue Operating Temp.	1150℃
Power supply	220V/2.5KW	220V/3KW	220V/3KW	220V/4KW	220V/6KW	380V/7.5KW	Depends on size
Heating element	High quality alloy resistance wire
Chamber material	High temperature polycrystal alumina ceramic fiber material
Temperature precision	±1℃
Thermocouple	N type
Temperature controller	YUDIAN intelligent microcomputer PID controller can program 30 segments
Electronic component	DELIXI make
Heating rate	≤ 25℃/min ( suggest 15℃/min for longer life using of furnace )
Safety protection	Overheat and thermocouple-break alarm
Certification	ISO9001 CE
Furnace shell	high quality cold-rolled steel sheets processing
Insulation	High quality thermal insulation material to ensure a good uniformity
Accessories	One pair of high temperature furnace gloves
	One pair of crucible stongs
Optional	Paperless recorder
	Stainless steel exhaust chimney
	Alumina crucible

FeedBack

Production Flow

Packaging & Shipping

Packing 1000C 1 liter Max temperature kiln for ceramic tiles:

1.The furnace body was warped with enrivonmental plastic stretch film, then fixed well on the fumigation-free pallet

2.Tailored polywood case, coupled perfectly with the pallet

3.Filled with polyfoam, fit well between the furnace body and the case in all sides

4.Easy-to-identify double-sided outer box print logos and shippment marks Delivery Time: 15 working days against receiving advanced payment Port: Shanghai/Qingdao

Company Information

Henan Sante Furnace Technology Co., Ltd. is a high-tech enterprise located in Luoyang area of Henan, China Free Trade Zone. SANTE products cover 1000℃~1800℃ Muffle furnace, Tube furnace, Vacuum furnace, High Temperature Furnace, 2000℃ Ultra-High Temperature Furnace, Dental furnace, Industrial chamber furnace, elevator furnace, Intelligent mobile car bottom furnace, Smelting furnace and so on

Our goal is to continuously meet the various demands for various kinds of high temperature heating treatment lab furnaces and to be the world first-class enterprise with providing excellent service and high-quality products for our cooperation partners!

exhibition

Certifications

Our company has passed ISO9001 quality system certificate, CE certificate and factory certificate. It also has got a number of
technical honors like “Scientific and Technologic Enterprise of Henan Province”, “Refractory Material Technology Sintering R&D
Center” issued by Science and Technology Department of Henan Province.

FAQ

1. who are we?
We are based in Henan, China, start from 2015,sell to Domestic Market(49.00%),Northern Europe(14.00%),Southern Europe(6.00%),Eastern Europe(6.00%),Western Europe(4.00%),Central America(4.00%),North America(3.00%),Africa(3.00%),Mid East(3.00%),Southeast Asia(2.00%),South America(2.00%),Eastern Asia(2.00%),Oceania(1.00%),South Asia(1.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
laboratory heating equipment,tube furnace,vacuum furnace,car bottom furnace,industrial furnace

4. why should you buy from us not from other suppliers?
Sante Furnace manufactures all kinds of muffle furnaces with 25 years experience. Our products are CE certfied, which have been exported to over 80 countries around the world.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU,Express Delivery;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

6. Contact information

International Sales
Mob: 86 18613706270
Whatsapp/wechat/Skype: 0086 18618613706270
Add: No. 6 Qingcheng Road, Luoyang | 471000, China
